DroneMAT
Advanced Ultrasonic Thickness Gauge for Industrial UAVs
![24.png](https://static.wixstatic.com/media/d82dd3_ccb5fa267fec4afab6a9787335e0edca~mv2.png/v1/crop/x_27,y_70,w_649,h_309/fill/w_519,h_247,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/24.png)
![23.png](https://static.wixstatic.com/media/d82dd3_94fcf9b1f9cc43399e91418a6d5d67ab~mv2.png/v1/fill/w_394,h_247,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/23.png)
![DroneMAT-icon1.png](https://static.wixstatic.com/media/d82dd3_e733aa1c22f5481689975677c58b2059~mv2.png/v1/fill/w_72,h_72,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/DroneMAT-icon1.png)
No surface preparation or couplant
![DroneMAT-icon2.png](https://static.wixstatic.com/media/d82dd3_0d565f4c1eaf469583892b2aeee0d888~mv2.png/v1/fill/w_72,h_72,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/DroneMAT-icon2.png)
Robust thickness measurements
![DroneMAT-icon3.png](https://static.wixstatic.com/media/d82dd3_e76d87d55083402da8d645c0b57a1b4b~mv2.png/v1/fill/w_72,h_72,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/DroneMAT-icon3.png)
Lightweight Compact & Modular
![DroneMAT-icon4.png](https://static.wixstatic.com/media/d82dd3_0ed5865d74854d0197064f9a2b0a627b~mv2.png/v1/fill/w_72,h_72,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/DroneMAT-icon4.png)
No force required from UAV to take measurements
Overview
DroneMAT is a electromagnetic acoustic transducer (EMAT) ultrasonic thickness (UT) gauge designed for industrial UAVs (Drones). It allows users to perform ultrasonic thickness inspections from drones in a more efficient, reliable and safer way. The modular and lightweight design allows conversion of any industrial drone to an aerial UT gauge, increasing the range of applications and utilization.
![Voliro10059-mod-840x475-1.jpg](https://static.wixstatic.com/media/d82dd3_e7e35e1cbc954f4fac0e2bc54ec4e2ee~mv2.jpg/v1/fill/w_297,h_168,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/Voliro10059-mod-840x475-1.jpg)
![DroneMAT-Silo-Inside-Contact-840x475-1.j](https://static.wixstatic.com/media/d82dd3_116d2e5b22024f9ea6d2deb443a1f933~mv2.jpg/v1/fill/w_298,h_168,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/DroneMAT-Silo-Inside-Contact-840x475-1_j.jpg)
![Voliro10023-mod-840x475-1.jpg](https://static.wixstatic.com/media/d82dd3_2988c05020164ad9a3355d548d4dfb44~mv2.jpg/v1/fill/w_297,h_168,al_c,q_80,usm_0.66_1.00_0.01,enc_auto/Voliro10023-mod-840x475-1.jpg)
-
Decrease cost of inspection vs the conventional way by increasing inspection speed and elimination of auxiliary equipment
-
Eliminate working at height by inspectors and reduce potential risks
-
Modular design allowing integration to any industrial drone (total payload < 700 gr)
-
Allows inspection on any metal surface - coated, unbonded paint or corroded
-
Independent sensor aligning to measurement surface
-
No contact required to perform measurements - gap up to 3 mm / misalignment (angle) 25 degrees
-
Measurement immune to drone noise
-
User friendly App with easy data management (including A-Scan and Inspection details)
FEATURES
EMAT Technology
-
EMAT technology allows significant advantages over standard piezoelectric thickness gauges in applications for drone inspections:
-
No paint removal required (non-contact up to 3 mm)
-
No surface preparation
-
No couplant required
-
Measures through unbonded paint
-
Sensor not required to be perpendicular to test material
-
Use in corroded areas
-
High temperature applications
![Technology-Comparison-A-840x475-1.jpg](https://static.wixstatic.com/media/d82dd3_647be6f5a19f4dc99e0b85c8251337b7~mv2.jpg/v1/fill/w_96,h_54,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/Technology-Comparison-A-840x475-1.jpg)
DroneMAT system in 2 configurations
Modular design for custom drones:
-
DroneMAT modular system for custom drone installation (< 700 grams)
-
Tablet with radio communication module
![Voliro10027-mod-840x475-1.jpg](https://static.wixstatic.com/media/d82dd3_1f3efce6bee54f0786af223a1fda9366~mv2.jpg/v1/fill/w_96,h_54,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/Voliro10027-mod-840x475-1.jpg)
Universal system for DJI Matrice 200/210/300:
-
Mast with DroneMAT module
-
Installation frame to connect to DJI Matrice drone
-
Tablet with radio communication module
